BIXOLON SLP-T400 BARCODE PRINTER

BIXOLON SLP-T400 is the most comprehensive and reliable model of industrial direct thermal/thermal transfer label printers in the marketplace today. The SLP-T400 is an ideal for a wide array of mission critical bar code labeling requirements including 2D, such as Maxicode, PDF417, QR Code and Data Matrix applications. In fact, where intricate two-dimensional bar coding is required for compliance labeling, small parts tracking, or product identification, the SLP-T400 has emerged as the printer of choice by large, multinational operations.

Category:

Description

Features and Specifications

Print Characteristics

Printing Method: Thermal Transfer, Direct Thermal

Printing Speed: SLP-T400: Up to 6 ips (152 mm/s)

SLP-T403: Up to 4 ips (100 mm/s)

Print Resolution: SLP-T400: 203 dpi / SLP-T403: 300 dpi

Printing Width: SLP-T400: Up to 104 mm / SLP-T403: Up to 105.7 mm

Printing Length: 6 ~ 1,000mm

Media Sensor: Transmissive, Reflective (adjustable), Ribbon-End, Head open

Media Characteristics

Media Type: Gap, Black Mark, Notch, Continuous, Fan-Fold

Media Width: 15 ~ 116 mm

Media Roll Diameter: Up to 130 mm

Media Thickness: 0.06 ~ 0.20 mm

Supply Method: Easy Paper Loading

Ribbon Characteristics

Ribbon Type: Wax, Wax / Resin, Resin

Ribbon Width: 33 ~ 110 mm

Ribbon Length: Up to 300 m

Core Inner Diameter: 12.5 / 25.4 mm

Physical Characteristics

Dimensions (W x L x H): 214 x 310 x 200 mm (8.42 x 12.20 x 7.87 inch)

Weight: 2.75 kg (6.06 lbs.)

Power: EnergyStar Certified, External Power Adaptor 100-240V AC, 50/60Hz

Performance Characteristics

Memory: 8MB SDRAM, 2MB FlashROM

Interface: Triple Interface

Standard: USB V1.1 FS + Serial + Parallel

Optional: USB V1.1 FS + Serial + Ethernet

Environment Characteristics

Temperature: Operating: 5 ~ 40 °C (41 ~ 104 °F)

Storage: -20 ~ 60 °C (-4 ~ 140 °F)

Humidity: Operating: 10 ~ 80% RH / Storage: 10 ~ 90% RH
Software
Emulation: SLCS, BPL-Z™, BPL-E™

Driver / Utility: Windows Driver, Linux CUPS Driver, Mac Driver, Virtual COM

USB/Ethernet Driver, Utility Program, Label Artist™

SDK: Android SDK

Fonts / Graphics / Symbologies

Character Sets:

  • 10 SLCS Resident Bitmap Fonts
  • One SLCS Resident Scalable Font
  • 23 Code Page

Graphics: Supporting user-defined fonts, graphics, formats, and logos

Barcode Symbologies: 1D: Coda Bar, Code 39, Code 93, Code 128, EAN-8, EAN-13, IMB, Interleaved 2-of-5, ITF, UCC/EAN- 128, UPC-A, UPC-E

2D: Data Matrix, MaxiCode, PDF417, QR Code
(select two only)
