BIXOLON SRP770 BARCODE PRINTER
BIXOLON SRP-770II is the first label printer developed with the technological power of Samsung, which has been proved in the POS printer market. The SRP-770II can print 5 ips (127 mm/sec) and can recognize various programming languages such as SLCS, BPL-Z™, BPL-E™ automatically, and also the width of the paper can be adjusted easily to the range of 1.5~4.2 inch so that it can be used for barcode printing as well as receipt printing. The various on-board interfaces including Serial, Parallel, and USB allow flexible system configuration.
Description
Features and Specifications
Print Characteristics
Print Method: Direct Thermal
Print Speed: Up to 5 ips (127 mm/s)
Print Resolution: 203 dpi
Print Width: Up to 104 mm
Print Length: 6 ~ 304 mm
Printing Length: 6 ~ 1,000mm
Media Sensor: Transmissive, Reflective, Head open
Media Characteristics
Media Type: Gap, Black Mark, Notch, Continuous, Fan-Fold
Media Width: 42 ~ 106 mm
Media Roll Diameter: Up to 130 mm
Media Roll Diameter: 0.06 ~ 0.20 mm
Supply Method: Easy Paper Loading
Physical Characteristics
Dimensions (W x L x H): 184 x 221 x 171 mm
(7.24 x 8.70 x 6.73 inch)
Weight: 1.65 kg (3.63 lbs.)
Power: External Power Adaptor 100-240V AC, 50/60Hz
Performance Characteristics
Memory: 512KB SDRAM, 2MB FlashROM
Interface: Triple Interface
USB V1.1 FS + Serial + Parallel
Environment Characteristics
Temperature: Operating: 0 ~ 40℃ (32 ~ 104℉)
Storage: -20 ~ 60℃ (-4 ~ 140℉)
Humidity: Operating: 10 ~ 80% RH
Software
Emulation: SLCS, BPL-Z™, BPL-E™
Driver: Windows Driver, Linux CUPS Driver, Mac Driver,
Virtual COM USB Driver, Utility Program, Label Artist™
SDK: Android SDK
Fonts / Graphics / Symbologies
Fonts:
- 10 SLCS Resident Bitmap Fonts
- One SLCS Resident Scalable Font
- 23 Code Page
Graphics: Supporting user-defined fonts, graphics, formats, and logos
Barcode Symbologies: 1D: Coda Bar, Code39, Code93, EAN-8, EAN-13, Interleaved 2-of-5, ITF, UCC/EAN-128, UPC-A, UPC-E
2D: Data Matrix, MaxiCode, PDF417, QR Code
