TM-T88IV EPSON USB Thermal Receipt Printer
Designed specifically for high-volume sales environments, the thermal TM-T88IV offers 25% faster printing than its predecessor, a redesigned case, two-color capability, and new easy-to-use features. With its 200mm per second print speed, enhanced graphics capability and increased user memory, the TM-T88IV delivers ultra-fast results. Unlike other printers, it prints text, barcodes, and graphics at the same fast speed to deliver intelligent receipts with customer impact whilst helping to increase transaction speed.
Description
PRINT TYPE
| Print method | Thermal line printing |
| Technology | Themal Line |
FONTS & STYLES
| Print Speed | 200 mm/sec |
| Column capacity receipt | Paper width 80 mm, 56 / 42 |
| Character size | 0.99 mm (W) x 2.4 mm (H) / 1.41 mm (W) x 3.39 mm (H) |
| Character set | 95 Alphanumeric, 48 International, 128 x 11 Graphic |
| Characters per inch | 20 cpi / 15 cpi |
| Dot density | 180 dpi x 180 dpi |
| Color Printing | Two colours |
PAPER
| Paper Types | Receipt |
| Paper size roll paper | 79.50 ± 0.50 (W) mm x dia 83.00 mm, 575.00 ± 5.00 (W) mm x dia 83.00 mm (option) |
INTERFACES
| Interfaces | RS-232, Drawer kick-out |
POWER
| Power Supply | PS-180 (option) |
| Power Consumption | standby: 0.1 A, Mean: 1.8 A |
| Operating voltage | 24 V |
GENERAL
| Product dimensions | 145 x 195 x 148 mm (Width x Depth x Height) |
| Product weight | 1.8 kg |
| Color | Epson Dark Gray / Epson Cool White |
| Installation | horizontally, vertically with wall mounting bracket |
| Interface connectors | D.K.D. function (2 drivers) |
| Noise Level | Operation: 55 dB (A) |
| Humidity | Operation 10% – 90%, Storage 10% – 90% |
| Temperature | Operation 5° C – 45° C, Storage -10° C – 50° C |
RELIABILITY
| Reliability | 52,000,000 MCBF (Lines), 360,000 MTBF (Hours) |
| Auto Cutter Life | 1,500,000 Cuts |
| Printer Life | 15,000,000 Lines |
| Print Head Life | 100 km – 100,000,000 pulses |
STANDARDS COMPLIANCE
| EMC Standards | CE marking |
| Safety standards | TÜV |
OTHER FEATURES
| Changeable interface | Yes |
| Cutter | Partial Cut |
| Sensors | Paper End Sensor, Paper Near End Sensor, Cover Open Sensor |
